Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA

Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA
Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA

बड़ी छवि :  Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA

उत्पाद विवरण:
Place of Origin: Zhejiang,China(Mainland)
ब्रांड नाम: JIELI
प्रमाणन: CE/ISO9001/CB/TUV
Model Number: JL-MUN
भुगतान & नौवहन नियमों:
Minimum Order Quantity: 1200 Piece/Pieces other
मूल्य: Negotiable
Packaging Details: Standard export carton or according to your request.
Delivery Time: Within 20 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,CASH
Supply Ability: 50000POLES/DAY
विस्तृत उत्पाद विवरण
हाई लाइट:

small circuit breaker

,

short circuit breaker



Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA





Quick Detail:



Place of Origin:

Zhejiang China (Mainland)

Brand Name:

JIELI

Model Number:

JL-MUN

Type:

Mini 3 phase circuit breaker

Poles Number:

4

OEM:

Available

Certificate:

CE,CCC,ISO9001

Tripping Curve:

B,C,D

Standard:

IEC60947

Breaking capacity:

4KA,6KA,10KA

Quality control:

In house









Description:



JL-MUN 3 phase circuit breaker  has protective function as shortage as overload.



And JL-MUN 3 Phase circuit breaker is used in lighting distribution system in commerce and dwelling, and protect fractional electrical motors. High protective grade IP20, high breaking capacity, reliable sensitive action, convenient, multi pole assembling, long life ect.



JL-MUN 3 Phase circuit breaker mainly adapted to circuit of AC 50Hz,250V in single pole, 415V in double, three, four poles for protecting overload and short circuit.



Also JL-MUN 3 Phase circuit breaker used in on or off the electrical apparatus and lighting circuit under the normal conditions.





Specifications:







                        Standard



          IEC/EN 60898-1

Electrical

features

   Rated current in

 A

 1  2  4 6 10 16 20 25 32 40 50  63

   Poles



               1P 2P 3P 4P

   Rated voltage Ue

 V

                 230/400

   Insulation coltage Ui

 V

                     500

   Rated frequency

 Hz

                  50/60Hz

   Rated breaking capacity

 A

            3000    4500    6000

   Rated impulse withstand voltage (1.2/50)Uipm

 V

                      6000

   Dielectric test voltage at and ind.Freq.for 1min

 KV

                         2

   Pollution degree



                         2

   Themo-magnetic release characteristic



                     B  C  D

Mechanical

features

   Electrical life



                       6000

   Machanical life



                      10000

   Contact position indicator



                       Yes

   Protection degree



                       IP 20

   Reference temperature of setting of thermal element

 °C

                         30

   Ambient temperature(with daily average≤35°C)

 °C

                      -5~+40

   Storage temperature

 °C

                     -25...+70

Installation

   Terminal connection type



Cable/U-type busbar/Pin-type busbar

   Terminal size top/bottom for cable

 mm²

 AWG

                           25

                         18-3

   Terminal size top/bottom for busbar

 mm²

 AWG

                           25

                         18-3

   Tightening torque

 N*m

 In-lbs.

                          3.0

                           22

   Mounting



  OnDIN rail FN 60715(35mm)

  by means of fast clip device

   Connection



   From top and bottom



About our company-JIELI







1. JIELI Electrical is abbreviation for" Alliance of JIELI Electrical Industry", with JILI brand and ICEDC brand.

2. JIELI Electrical have 29 members and more than 2000 employers, all of the plants area are about 50000 square meters.

3. JIELI Electrical devoted in producing low-voltage circuit breaker and other related products. .

4. At present, JIELI main products MCB,MCCB,RCCB, Distribution box, AC contactor, Relay, Switch and more than thousands electrical goods spare parts.



Our service:







1. Samples: provide free samples.

2. Package: all products will be well packed before shipping.

3. Warranty: all products have 2-5 years warranty.

4. Delivery: within 30days after received the deposit.

5. Provide OEM and ODM service.

6. We can help you with any of your idea to design and put it into production.

7. Provide help for building factories, such as: spare parts, technical questions, financial matter, management problem , approach of sales...
