House MBC Mini Circuit Breaker Automatic Reset Low Voltage 63A IEC60898

चीन House MBC Mini Circuit Breaker Automatic Reset Low Voltage 63A IEC60898 आपूर्तिकर्ता

बड़ी छवि :  House MBC Mini Circuit Breaker Automatic Reset Low Voltage 63A IEC60898

उत्पाद विवरण:

Place of Origin: Zhejiang,China(Mainland)
ब्रांड नाम: JIELI
प्रमाणन: CE/ISO9001/IEC60898
Model Number: JL-EPN

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 1200pieces
मूल्य: Negotiable
Packaging Details: Standard export carton or according to your request.
Delivery Time: Within 20 days
Payment Terms: L/C,D/P,T/T, Western Union, MoneyGram
Supply Ability: 50000POLES/DAY
Contact Now
विस्तृत उत्पाद विवरण



House MBC Mini Circuit Breaker Automatic Reset Low Voltage 63A IEC60898





Quick Detail:



Place of Origin: Zhejiang, China (Mainland)

Brand Name: JIELI

Model Number: JL-EPN

Type: Mini circuit breaker

Poles Number: 1P,2P,3P,4P

Products: EPN

Current: 1A to 63A

Tripping curves: B, C, D

Operating voltage: up to 415 V

AC insulation voltage:500 V

Auxiliaries: shunt tripping, under voltage tripping, over voltage tripping

Breaking capacity:4.5KA, 6KA,10KA

Standards: IEC/EN 60898 or IEC/EN 60947-2, IEC60947-3

Insulation: Class 2





Description:



JL-EPN series mini circuit breaker is neoteric in structure, light in weight, reliable and excellent in performance.

The frame and parts of JL-EPN mini circuit breaker adopt plastics of high fire resistant and shockproof.

The product JL-EPN series mini circuit breaker complies with IEC 60898 & GB10963-1999.

JL-EPN mini circuit breaker has two kinds of functions: overload protection and short circuit protection.

We are manufacturer of electrical products, mainly produces mini circuit breaker and residual current circuit breaker.





Applications:



JL-EPN series mini circuit breaker is used in lighting distribution system or motor distribution system for protecting overload and short circuit in the system.



JL-EPN series mini circuit breaker is used in residential building, non-residential building, energy source industry and infrastructure.





Specifications:



Electrical features

            Rated current In

A

    1, 2, 3,4,6, 10, 16, 20, 25, 32, 40, 50, 63

Poles

P

1.2.3.4

Rated voltage Ue

V

240/415

Insulation voltage Ui

V

500

Rated frequency

Hz

50/60

Rated breaking capacity

A

1-32A/6000A,40-63A/4500A,

Rated impulse withstand voltage (1.2/50) Uimp

V

4000

Dielectric test voltage at ind. Freq. for 1 min

Kv

2

Pollution degree



2

Thermo-magnetic release characteristic



B, C, D

Mechanical features

Electrical life

t

4000

Mechanical life

t

10000

Protection degree



IP20

Reference temperature for setting of thermal element

°C

30

Ambient temperature (with daily average≤35°C)

°C

-5~+40 (special application please refer to temperature compensation correction)

Storage temperature

°C

-25~+70





Competitive Advantage:



♥The world's first supplier of MCB OJM service.

♥The world's first supplier of MCB spare parts solution.

♥To be the first international MCB market solution supplier.

♥The world's first supplier of building MCB factory solution





About our company-JIELI:



1.JIELI Electrical is abbreviation for" Alliance of JIELI Electrical Industry", with JIELI brand and ICEDC brand.

2.JIELI Electrical have 29 members and more than 2000 employers, all of the plants area are about 50000 square meters.

3.JIELI Electrical devoted in producing low-voltage circuit breaker and other related products. .

4.At present, JIELI main products MCB,MCCB,RCCB, Distribution box, AC contactor, Relay, Switch and more than thousands electrical goods spare parts.



Our service:







1. Samples: provide free samples.

2. Package: all products will be well packed before shipping.

3. Warranty: all products have 2-5 years warranty.

4. Delivery: within 30days after received the deposit.

5. Provide OEM and ODM service.

6. We can help you with any of your idea to design and put it into production.

7. Provide help for building factories, such as: spare parts, technical questions, financial matter, management problem , approach of sales...
